Port RJ-45 | 4 x 10/100/1000M |
---|---|
Port USB | 2 x USB3.0 |
Port eSATA | 1 x eSATA |
HDD Interface | 4 x 3.5"/2.5" SATA HDD/SSD (drives not included) |
Brand | Synology |
---|---|
Model | RS820+ |
Form Factor | 1U |
---|---|
Processor | Intel Atom C3538 Quad-core 2.1GHz |
Default/ Max. Memory | 2 GB DDR4 Non-ECC onboard (expandable up to 18 GB) |
RAID | Synology Hybrid RAID (SHR), Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10 |
---|
Supported Protocols | SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN (PPTP, OpenVPN , L2TP) |
---|
Power | 100V to 240V AC, 50/60Hz, single phase |
---|
Features | 4-core, 2.1 GHz CPU with AES-NI support. 2 GB DDR4 memory expandable up to 18 GB Outstanding 10GbE sequential performance at over 1,621 MB/s reading and 599 MB/s writing Scale up to 8 drives with Synology Expansion Unit RX418 One PCIe 3.0 slot for an optional 10GbE add-in network interface card, or an M2D18 M.2 SSD adapter card Advanced Btrfs file system offering 65,000 system-wide snapshots and 1,024 snapshots per shared folder Synology High Availability (SHA) providing continuous services with seamless transitioning between clustered servers |
---|---|
Usage | High read/write performance with RAID |
Temperature | Operating temperature: 0°C to 35°C (32°F to 95°F) Storage temperature: -20°C to 60°C (-5°F to 140°F) |
---|---|
Humidity | 5-95% R.H |
Dimensions | 1.73" x 16.95" x 18.02" /1.73" x 18.90" x 19.36" (with server ears) |
---|---|
Weight | 14.11 lbs. |
Package Contents | 1 x RS820+ Main Unit 1 x Quick Installation Guide 1 x Accessory pack 1 x AC power cord |
---|
Synology RackStation RS820+/RS820RP+ is designed for businesses pursuing an effective and centralized data management. It comes with four drive trays and 1GbE LAN ports and supports an optional 10GbE network or M.2 SSD adapter card, providing fast data transmission and reducing IO latency.
